Death By Audio MOONBEAM Phaser

At its core, the Moonbeam Phaser houses two fully analog 6-stage phase shifter engines. You can tap into each stage individually and hear its unique movement as the display morphs through a spectrum of colors that mirror the sound. To unleash the full potential of this unique circuit, we supercharged the FREQ control far beyond the usual range. Drift slowly through 2-minute phase sweeps, dive into liquid swirls, or blast off into ring-modulated frequency shifts.
Combined with the DEPTH control, the Moonbeam Phaser opens a vast spectrum of refracted phasing tones- from shimmering rotary-style warbles to deep, resonant bends. And if one phaser wasn’t enough, we’ve packed two phasers in one, letting you bring your guitar, bass, synth, or anything you can imagine into mesmerizing stereo with the click of a stomp.
Part of Death By Audio’s Destroyer Series, the Moonbeam Phaser sports the line’s signature look: a compact footprint, glowing vintage-style LED display, and minimal controls that conceal a world of sonic madness. Each Destroyer pedal delivers a distinct, over-the-top effect in a smaller, stage-friendly box - together forming a family of beautifully chaotic tone machines in stereo.

KEY FEATURES
● Six Phasers In One - Each of the six phase stages has its own unique sound, from
classic modulation to wild, otherworldly bends.
● Fully Analog Phaser - Real analog circuitry delivering extreme, organic modulation in a
digital world.
● Full Stereo Modulation - True stereo operation expands your sound from mono to
massive.
● Ultra-High Headroom - Handles the hottest signals without breaking up or losing depth.
● Super-Slow Phasing - Over two minutes of evolving, slow-motion phase sweeps.
● Hyper Speed To Ring Modulation - Crank the FREQ knob for blistering,
ring-modulated chaos.
● Adjustable Depth - Unlike the phasers of yore, we leave the control in your hands so
you can dial in anything from subtle shimmer to full-on resonance.
● Moving Light Indicator - Color-coded display shows the active stage and follows the
LFO.
● Pedalboard-Friendly - A bite-sized package with a massive sound.
● Tour-Grade Build Quality - Rugged enclosure, quality components, hand-assembled,
and built to last.

CONTROLS

PHASE SELECTOR - Selects the number of phaser stages. Ranges from one to six.
1 (RED) - A sweeping high pass filter and tremolo.
2 (YELLOW) - A sweeping notch filter with resonant peaks on each side.
3 (GREEN) - A cross between a phaser and a harmonic tremolo.
4 (CYAN) - The most famous, classic phaser sound you know and love.
5 (BLUE) - Adds in more intense resonance and treble focus to the 4-phase sound.
6 (PURPLE) - A full, bassy, and chewy-sounding phaser sound.
FREQ - Adjusts the speed of the phaser’s movement. Ranges from ultra-slow 0.006Hz
harmonic drifts to lightning-fast 130Hz sweeps.
DEPTH - Controls the intensity and character of the phaser stages, shaping the depth of the sweep and the resonance of the effect.
INTERNAL CONTROL
Access this control by removing the backplate of the Moonbeam Phaser.
INPUT CONFIGURATION SWITCH- Switch between mono TS and stereo TRS input.
○ MONO INPUT - Standard mono or mono-to-stereo operation. Lights up
“M” on the faceplate when active.
○ STEREO INPUT - Full stereo operation. Lights up “S” on the faceplate when active.
INPUTS AND OUTPUTS
The Moonbeam Phaser features TRS stereo input and output for mono or stereo operation.
● MONO - Use a TS cable for both INPUT and OUTPUT.
● MONO TO STEREO - Use a TS cable for INPUT and a TRS cable for OUTPUT.
Note: Set MONO/STEREO internal switch to Mono Input.
● STEREO - Use a TRS cable for both INPUT and OUTPUT.
Note: Set MONO/STEREO internal switch to Stereo Input.

SPECS
DIMENSIONS - 5.16" x 2.76" x 2.38" (including hardware)
WEIGHT - 10.3 oz
POWER The Moonbeam Phaser operates on a standard 9V DC power supply (2.1mm, center-negative). The pedal draws 72mA of current when engaged.

WARRANTY
Lifetime warranty.
